BR
Cement-coated wire wound resistors
BR Cemented wire wound resistors from KRAH. Here you find the technical data & scope of application.
technical datadimensions (LxWxH)
12 x 4 x 4 … 52 x 12 x 12 mm
product features
Cemented wire wound resistors with axial leads, with endcaps
resistance range min
0,15 Ω
tolerance min ±
1 %
tolerance max ±
10 %
resistance range max
110000 Ω
rated power max
18 W
rated power min
3 W
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Control-resistor #Ballast-resistor #E-Mobility #Battery-Management #Industry #Automation-technology #Power-Engineering #Power-Electronics #Transport-and-Logistics #Ceramic-carrier-cement-coated #Air-cooled
DWF
Cement coated wire wound resistors
DWF Cemented Wire Resistors from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
47 x 11 x 11 … 60 x 11 x 11 mm
product features
Cement coated wire wound resistors with long solder tail
tolerance min ±
5 %
resistance range max
1 Ω
rated power min
5 W
rated power max
5 W
resistance range min
10,0 Ω
resistance range max
15000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Control-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Power-Electronics #Transport-and-Logistics #Ceramic-carrier-cement-coated #Air-cooled
FH
Wire wound resistors in ceramic casing
FH wire wound resistors in ceramic casing by KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
18 x 7 x 8.3 … 75 x 9 x 10 mm
product features
Vertical mounting - Ceramic tube
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
4 W
rated power max
17 W
resistance range min
0,15 Ω
resistance range max
82000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Balancing-resistor #Ballast-resistor #Industry #Automation-technology #Power-Electronics #Ceramic-casing #Air-cooled
FHPR
High power resistors in aluminum casing
FHPR High power resistors in aluminum casing by KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
135 x 60 x 90 … 305 x 60 x 90 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
200 W
rated power max
500 W
resistance range min
0,30 Ω
resistance range max
666 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
FHPR/UL
High power resistors in aluminum casing UL-registered (UL 508)
FHPR/UL High power resistors in aluminum casing UL-registered (UL 508) by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
135 x 60 x 90 … 305 x 60 x 90 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
150 W
rated power max
400 W
resistance range min
0,3 Ω
resistance range max
666 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
FTH
Wire wound resistors in ceramic casing
FTH wire wound resistors in ceramic casing of KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
18 x 9 x 10 … 75 x 9 x 10 mm
product features
Spring fusible solder joint – Vertical mounting terminal – Ceramic tube
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
1.5 W
rated power max
10 W
resistance range min
0,11 Ω
resistance range max
82000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Balancing-resistor #Ballast-resistor #Industry #Automation-technology #Power-Electronics #Ceramic-casing #Air-cooled
FX
Wire wound resistors in ceramic casing
FX wire wound resistors in ceramic casing by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
18 x 7 x 8.3 … 75 x 9 x 10 mm
product features
Axial wire terminal - Ceramic tube
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
4 W
rated power max
17 W
resistance range min
0,051 Ω
resistance range max
82000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Balancing-resistor #Industry #Automation-technology #Power-Electronics #Ceramic-casing #Air-cooled
GF
Vitreous enamelled wire wound resistors
GF Vitreous enamelled wire wound resistors by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
55 x 13 x 13 … 100 x 24 x 24 mm
product features
Wire wound vitreous resistors with radial lugs
tolerance min ±
2 %
tolerance max ±
10 %
rated power min
25 W
rated power max
80 W
resistance range min
1,0 Ω
resistance range max
130000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Equipment-and-plant-construction #Power-Electronics #Transport-and-Logistics #Ceramic-carrier-vitreous-enamelled #Air-cooled
GF...V
Vitreous enamelled wire wound resistors
GF...V Vitreous enamelled wire wound Resistors from KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
55 x 13 x 13 … 100 x 24 x 24 mm
product features
Wire wound vitreous resistors with radial lugs and adjustable lug
resistance range min
10 Ω
resistance range max
10 Ω
rated power min
20 W
rated power max
64 W
resistance range min
5,01 Ω
resistance range max
5100 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Speed-control #Adjustable-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Ceramic-carrier-vitreous-enamelled #Air-cooled
GK
Vitreous enamelled wire wound resistors
GK Vitreous enamelled wire wound resistors made by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
55 x 13 x 13 … 265 x 24 x 24 mm
product features
Wire wound vitreous resistors for ferrules
tolerance min ±
2 %
tolerance max ±
10 %
rated power min
25 W
rated power max
300 W
resistance range min
2,2 Ω
resistance range max
330000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Equipment-and-plant-construction #Power-Electronics #Transport-and-Logistics #Ceramic-carrier-vitreous-enamelled #Air-cooled
GKD
Vitreous enamelled wire wound resistors
GKD Vitreous enamelled wire wound resistors from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
14 x 5 x 5 … 50 x 9 x 9 mm
product features
Wire wound vitreous resistors with axial wire leads, with end caps
tolerance min ±
2 %
tolerance max ±
10 %
rated power min
5 W
rated power max
20 W
resistance range min
1,5 Ω
resistance range max
56000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Equipment-and-plant-construction #Power-Electronics #Transport-and-Logistics #Ceramic-carrier-vitreous-enamelled #Air-cooled
GS...V
Vitreous enamelled wire wound resistors
GS...V Vitreous enamelled wire wound resistors from KRAH. Here you can find the technical data & application areas.
technical datatolerance
±5% … ±10% %
rated power
12 - 400 W W
dimensions (LxWxH)
45 x 9 x 9 … 330 x 36 x 36 mm
resistance range
4R3 … 36K
product features
Wire wound vitreous resistors with tabs and adjustable terminal
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
12 W
rated power max
400 W
resistance range min
4,3 Ω
resistance range max
36000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Speed-control #Adjustable-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Ceramic-carrier-vitreous-enamelled #Air-cooled
GSB...V
Vitreous enamelled wire wound resistors
GSB...V Vitreous enamelled wire wound resistors from KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
100 x 30 x 30 … 330 x 30 x 30 mm
product features
Wire wound resistors with corrugated ribbon or round wire and adjustable lug
tolerance min ±
10 %
tolerance max ±
10 %
rated power min
120 W
tolerance max ±
400 %
resistance range min
0,15 Ω
resistance range max
36000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Speed-control #Adjustable-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Ceramic-carrier-vitreous-enamelled #Air-cooled
HPR
High power resistors in aluminum casing
HPR High power resistors in aluminum casing from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
102 x 40 x 21 … 337 x 60 x 31 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
60 W
rated power max
500 W
resistance range min
0,10 Ω
resistance range max
7500 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
HPR 800 - 2500
High power resistors in aluminum casing
HPR 800 - 2500 High power resistors in aluminum casing from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
340 x 50 x 100 … 800 x 50 x 100 mm
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
750 W
rated power max
2000 W
resistance range min
0,90 Ω
resistance range max
330 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
HPRF
High power resistors in aluminum casing
HPRF - High power resistors in aluminum casing from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
110 x 80 x 15 … 216 x 80 x 15 mm
tolerance min ±
1 %
rated power max
10 W
rated power min
100 W
rated power max
200 W
resistance range max
200 Ω
resistance range min
1,9 Ω
tolerance max ±
10 %
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
HPRF 600...C/UL
High power resistors in aluminium profile UL-registered (UL 508)
HPRF 600...C/UL High power resistors in aluminium profile UL-registered (UL 508) from KRAH. Here you can find the technical data & application areas.
technical datatolerance
±5% … ±10% %
rated power
100 - 240 W W
dimensions (LxWxH)
216 x 80 x 30 … 216 x 80 x 30 mm
resistance range
6R … 200R
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
100 W
rated power max
240 W
resistance range min
6 Ω
resistance range max
200 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
HPRF 600/UL
High power resistors in aluminium profile UL-registered (UL 508)
HPRF 600/UL high power resistors in aluminum profile UL registered (UL 508) from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
216 x 80 x 30 … 216 x 80 x 30 mm
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
150 W
rated power max
240 W
resistance range min
6 Ω
resistance range max
200 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
HPRF T
High power resistors in aluminum casing
HPRF T high power resistors in aluminum profile from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
110 x 80 x 15 … 216 x 80 x 15 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
100 W
rated power max
200 W
resistance range min
1,9 Ω
resistance range max
200 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
HPRF T/UL
High power resistors in aluminum casing UL-registered (UL 508)
HPRF T/UL high power resistors in aluminum profile UL-registered (UL 508) from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
110 x 80 x 15 … 216 x 80 x 15 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
100 W
rated power max
200 W
resistance range max
200 Ω
resistance range min
1,9 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
HPRF...C
High power resistors in aluminum casing
HPRF...C high power resistors in aluminum casing by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
110 x 80 x 15 … 216 x 80 x 15 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
100 W
rated power max
200 W
resistance range min
1 Ω
dimensions (LxWxH)
200 mm
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
HPRF...C/UL
High power resistors in aluminum casing UL-registered (UL 508)
HPRF...C/UL High power resistors in aluminum profile UL-registered (UL 508) from KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
110 x 80 x 15 … 216 x 80 x 15 mm
rated power min
1 W
tolerance max ±
10 %
rated power min
100 W
rated power max
200 W
resistance range
1,9
resistance range max
200 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Air-cooled
HPRF/UL
High power resistors in aluminum casing UL-registered (UL 508)
HPRF/UL high power resistors in aluminum profile UL registered (UL 508) from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
110 x 80 x 15 … 216 x 80 x 15 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
100 W
rated power max
200 W
resistance range min
1,9 Ω
resistance range max
200 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
HPRS
High power resistors in aluminum casing
HPRS - high power resistors in aluminum profile from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
100 x 33 x 12.5 … 100 x 33 x 12.5 mm
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
30 W
rated power max
30 W
resistance range min
0,30 Ω
resistance range max
30000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Discharge-resistor #Heating-resistor #Charge-and-discharge-resistor #Balancing-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Power-Electronics #Aluminium-housing #Air-cooled
HPRS HS
High power resistors in aluminum casing
HPRS HS - High power resistors in aluminum casing from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
80 x 38.5 x 8 … 80 x 38.5 x 8 mm
tolerance min ±
0 %
tolerance max ±
10 %
rated power min
40 W
rated power max
70 W
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Power-Electronics #Aluminium-housing #Air-cooled
HWG / HPR
High power resistors in a housing
HWG / HPR high power resistors in housing from KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
485 x 95 x 170 … 845 x 185 x 170 mm
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
750 W
rated power max
3000 W
resistance range min
0,45 Ω
resistance range max
320 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Housing-units #Air-cooled
HWG / VHPR
High power resistors in a housing
HWG / VHPR high power resistors in housing from KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
245 x 70 x 95 … 445 x 300 x 120 mm
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
100 W
rated power max
2000 W
resistance range min
0,1 Ω
resistance range max
30000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Housing-units #Air-cooled
KBD
Wire wound resistors in ceramic casing
KBD wire wound resistors in ceramic casing from KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
18 x 6.5 x 6.5 … 75 x 9 x 9 mm
product features
low-valued - low-induction
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
4 W
rated power max
17 W
resistance range min
0,0062 Ω
resistance range max
0,20 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Balancing-resistor #Ballast-resistor #Industry #Automation-technology #Power-Electronics #Ceramic-casing #Air-cooled
KFD
Wire wound resistors in ceramic casing
KFD wire wound resistors in ceramic casing from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
18 x 6.5 x 6.5 … 75 x 9 x 9 mm
product features
Axial wire terminal - Ceramic tube
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
4 W
tolerance max ±
17 %
resistance range min
0,051 Ω
resistance range max
82000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Balancing-resistor #Ballast-resistor #Industry #Automation-technology #Power-Electronics #Ceramic-casing #Air-cooled
KRGG
Wire wound resistors in ceramic casing
KRGG wire wound resistors in ceramic casing from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
20 x 11 x 7 … 35 x 16 x 13 mm
product features
High power resistors - vertical, ceramic case
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
2 W
rated power max
100 W
resistance range min
0,2 Ω
resistance range max
8000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Balancing-resistor #Precharge-resistor #Industry #Automation-technology #Power-Electronics #Ceramic-casing #Air-cooled
KRX27-8
High power resistors in a galvanised sheet steel casing
KRX27-8 high power resistors in galvanized sheet steel casing from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
47.6 x 19.1 x 19.1 … 163.5 x 22 x 22 mm
tolerance max ±
5 %
rated power min
10 W
rated power min
20 W
rated power max
75 W
resistance range min
0,15 Ω
resistance range max
51000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Air-cooled #Steel-Stainless-Steel-housing
KST
Wire wound resistors in ceramic casing
KST wire wound resistors in ceramic casing by KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
50 x 13 x 13 … 100 x 13 x 13 mm
product features
Connector blades, soldering connections or radial leads
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
15 W
rated power max
30 W
resistance range min
0,18 Ω
resistance range max
75000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Balancing-resistor #Ballast-resistor #Industry #Automation-technology #Power-Electronics #Ceramic-casing #Air-cooled
RX
Vitreous enamelled wire wound resistors
RX Vitreous enamelled wire wound resistors by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
44.4 x 12.7 x 12.7 … 266.7 x 33.3 x 33.3 mm
product features
Wire wound vitreous resistors with radial lugs and adjustable lug to MIL-R-19365
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
11 W
rated power max
240 W
resistance range min
1 Ω
resistance range max
47000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Speed-control #Adjustable-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Ceramic-carrier-vitreous-enamelled #Air-cooled
RXLG-PTC
High power resistors in aluminium profile
RXLG-PTC high power resistors in aluminum profile by KRAH. Here you can find the technical data & application areas.
technical datarated power min
35 W
rated power max
70 W
resistance range min
175 Ω
resistance range max
1750 Ω
#Brake-resistor #Industry #Automation-technology #Power-Electronics #Aluminium-housing #Air-cooled #PTC
RXLG-Z/UL
High power resistors in aluminum casing UL-registered (UL 508)
RXLG-Z/UL - High load resistors in aluminum profile UL registered (UL 508) by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
80 x 40 x 7 … 165 x 40 x 7 mm
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
20 W
rated power max
65 W
resistance range min
3 Ω
resistance range max
11000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Power-Electronics #Aluminium-housing #Air-cooled
SFD
Wire wound resistors
SFD wire wound resistors by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
16 x 5 x 5 … 35 x 5 x 5 mm
product features
Axial wire terminal - Silicon cemented
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
1 W
rated power max
3 W
resistance range min
0,051 Ω
dimensions (LxWxH)
33000 mm
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Control-resistor #Precharge-resistor #Industry #Automation-technology #Power-Electronics #Fiber-glass-carrier #Air-cooled
SFR
Wire wound resistors
SFR wire wound resistors by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
19 x 5 x 5 … 54 x 5 x 5 mm
product features
Radial lead - Silicon cemented
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
2.5 W
rated power max
8 W
resistance range min
0,1 Ω
resistance range max
27000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Control-resistor #Ballast-resistor #Industry #Automation-technology #Power-Electronics #Fiber-glass-carrier #Air-cooled
UK
Unprotected wire wound resistors
UK Unprotected wire wound resistors by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
300 x 126 x 126 … 600 x 126 x 126 mm
product features
Unprotected wire wound resistors with flashover guard ferrules
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
450 W
rated power max
1000 W
resistance range min
2 Ω
resistance range max
1000000 Ω
#Load-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Air-cooled #Open-coil-resistors
VHPR
High power resistors in aluminum casing
VHPR High power resistors in aluminum casing by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
102 x 40 x 21 … 407 x 60 x 31 mm
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
60 W
rated power max
560 W
resistance range min
0,1 Ω
resistance range max
1800 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
VHPR 3phasig
High power resistors in aluminum casing
VHPR 3-phase high power resistors in aluminum casing from KRAH. Here you can find the technical data & application areas.
technical datarated power min
200 W
rated power max
500 W
resistance range min
0,5 Ω
resistance range max
25 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Customized-solutions #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
VHPR T
High power resistors in aluminum casing including temperature sensor
VHPR T high power resistors in aluminum profile with temperature sensor by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
102 x 40 x 21 … 407 x 60 x 31 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
60 W
rated power max
560 W
resistance range min
0,1 Ω
resistance range max
1800 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
VHPR...C
High power resistors in aluminum casing
VHPR...C high power resistors in aluminum casing by KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
102 x 40 x 21 … 407 x 60 x 31 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
200 W
rated power max
560 W
resistance range min
0,3 Ω
resistance range max
666 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Air-cooled
VHPR...C/UL
High power resistors in aluminum casing UL-registered (UL 508)
VHPR...C/UL High power resistors in aluminum casing UL registered (UL 508) by KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
102 x 40 x 21 … 407 x 60 x 31 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
200 W
rated power max
560 W
resistance range min
0,3 Ω
resistance range max
666 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
VHPR/UL
High power resistors in aluminum casing UL-registered (UL 508)
VHPR/UL high power resistors in aluminum casing UL registered (UL 508) by KRAH. Here you can find the technical data & scope of application.
technical datadimensions (LxWxH)
102 x 40 x 21 … 407 x 60 x 31 mm
tolerance min ±
1 %
tolerance max ±
10 %
rated power min
60 W
rated power max
560 W
resistance range min
0,1 Ω
resistance range max
750 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Aluminium-housing #Air-cooled
WD
High power resistors in aluminum casing
WD - High power resistors in aluminum casing by KRAH. Here you can find the technical data & scope of application.
technical datadimensions (LxWxH)
16.8 x 17 x 9 … 127 x 73 x 45 mm
rated power min
10 W
rated power max
300 W
resistance range max
100000 Ω
#Load-resistor #Filter-resistor #Heating-resistor #Balancing-resistor #Ballast-resistor #Industry #Automation-technology #Power-Electronics #Aluminium-housing #Air-cooled
ZDFI
Cement-coated wire wound resistors
ZDFI Cement-coated Wire Resistors by KRAH. Here you can find the technical data & scope of application.
technical datadimensions (LxWxH)
50 x 9 x 27 … 250 x 12 x 45 mm
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
40 W
rated power max
280 W
resistance range min
0,022 Ω
resistance range max
100000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Control-resistor #Ballast-resistor #Industry #Automation-technology #Equipment-and-plant-construction #Power-Electronics #Ceramic-carrier-cement-coated #Air-cooled
ZDVW/ST
Cement-coated wire wound resistors
ZDVW/ST Cement-coated Wire Wound Resistors by KRAH. Here you will find the technical data & scope of application.
technical datadimensions (LxWxH)
63 x 13 x 13 … 125 x 13 x 25 mm
product features
Cemented wire wound resistors, square section, with flat-type connections and mounting clips
tolerance min ±
2 %
tolerance max ±
10 %
rated power min
25 W
rated power max
75 W
resistance range min
1 Ω
resistance range max
80000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Heating-resistor #Charge-and-discharge-resistor #Control-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Power-Electronics #Ceramic-carrier-cement-coated #Air-cooled
ZO
Heavy-duty resistors with special resistance ribbon
ZO Heavy-duty resistors with special resistance ribbon by KRAH. Here you can find the technical data & scope of application.
technical datadimensions (LxWxH)
117 x 57 x 57 … 708 x 57 x 57 mm
tolerance min ±
10 %
tolerance max ±
10 %
rated power min
90 W
rated power max
3188 W
resistance range min
0,027 Ω
resistance range max
5,15 Ω
#Current-limiting-resistor #Adjustable-resistor #Charge-and-discharge-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Mechanical-Engineerung #Transport-and-Logistics #Air-cooled #Open-coil-resistors
ZSB
Cement-coated wire wound resistors
ZSB Cement-coated wire wound resistors by KRAH. Here you can find the technical data & scope of application.
technical datadimensions (LxWxH)
100 x 30 x 30 … 330 x 30 x 30 mm
product features
Cemented wire wound resistors with corrugated ribbon or round wire and with radial tabs
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
75 W
rated power max
270 W
resistance range min
0,1 Ω
resistance range max
270000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Ceramic-carrier-cement-coated #Air-cooled
ZSB...V
Cement-coated wire wound resistors
ZSB...V Cement-coated wire wound resistors by KRAH. Here you will find the technical data & scope of application.
technical datadimensions (LxWxH)
100 x 30 x 30 … 330 x 30 x 30 mm
product features
Cemented wire wound resistors with corrugated ribbon or round wire and with and adjustable lug
tolerance min ±
10 %
tolerance max ±
10 %
rated power min
55 W
rated power max
180 W
resistance range min
0,1 Ω
resistance range max
36000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Speed-control #Adjustable-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Automation-technology #Power-Engineering #Equipment-and-plant-construction #Power-Electronics #Ceramic-carrier-cement-coated #Air-cooled
ZDRS
Cement-coated wire wound resistors
ZDRS Cement-coated Wire Wound Resistors by KRAH. Here you can find the technical data & scope of application.
technical datadimensions (LxWxH)
45 x 9 x 9 … 330 x 36 x 36 mm
product features
Cemented wire wound resistors with spotwelded radial tabs (with adjustable lugs)
tolerance min ±
5 %
tolerance max ±
10 %
resistance range min
0,62 Ω
rated power min
6 W
rated power max
300 W
resistance range max
620000 Ω
#Current-limiting-resistor #Load-resistor #Brake-resistor #Filter-resistor #Speed-control #Adjustable-resistor #Charge-and-discharge-resistor #Ballast-resistor #Industry #Equipment-and-plant-construction #Power-Electronics #Ceramic-carrier-cement-coated #Air-cooled
KRX
Wire wound resistors in ceramic casing
KRX wire wound resistors in ceramic casing from KRAH. Here you will find the technical data & application areas.
technical datadimensions (LxWxH)
24 x 9 x 9 … 63.5 x 12.5 x 12.5 mm
product features
Radial lead - Ceramic tube
tolerance min ±
5 %
rated power max
10 W
rated power min
3 W
rated power max
20 W
resistance range min
0,2 Ω
resistance range max
36000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Balancing-resistor #Ballast-resistor #Industry #Automation-technology #Power-Electronics #Ceramic-casing #Air-cooled
KRX27-4H
Wire wound resistors in ceramic casing
KRX27-4H wire wound resistors in ceramic casing from KRAH. Here you can find the technical data & application areas.
technical datadimensions (LxWxH)
63.5 x 12.5 x 12.5 … 90 x 19 x 19 mm
product features
Square section, with flat-types plug connections and mounting clip
tolerance min ±
5 %
tolerance max ±
10 %
rated power min
20 W
rated power max
40 W
resistance range min
1 Ω
resistance range max
20000 Ω
#Load-resistor #Brake-resistor #Filter-resistor #Charge-and-discharge-resistor #Balancing-resistor #Ballast-resistor #Industry #Automation-technology #Power-Electronics #Ceramic-casing #Air-cooled
LCRXG
Enamelled, liquid cooled pipe resistor
LCRXG - Enamelled, liquid cooled pipe resistor made by KRAH. Here you can find the technical data & application areas.
technical datatolerance max ±
10 %
rated power min
1000 W
rated power max
2000 W
dimensions (LxWxH)
331 x 44 x 93 mm
tolerance min ±
5 %
#Filter-resistor #Industry #Automation-technology #Power-Electronics #Liquid-cooled
